• Fast CPU of Intel® Baytrail-D J1900
• Rich I/O Port Combinations
• Industrial Grade Aluminum Case
• 64GB Hard Disk
| CPU | Intel® Celeron® Processor J1900 |
| Memory | DDR3L 1333 4G (up to 8GB) |
| Storage | 320GB HDD or up / 64G SSD (up to 256GB) |
| OS Support | Windows 7, Windows 8.1, Windows Embedded 8.1 Industry, Windows 10, Windows 10 IOT, POS Ready 7, Linux (ubuntu) |
| I/O Port | DC IN(DC 2.5) |
| POWER Switch | |
| RESTART Switch | |
| 1×HDMI | |
| 1×VGA | |
| 4×USB2.0 | |
| 2×USB3.0 | |
| 1×LAN | |
| 1×MIC | |
| 1×LINE | |
| 4*COM(DB9) | |
| PW LED | |
| SW LED | |
| HDD LED | |
| 1*Antenna | |
| 1*PS/2 MS | |
| 1*PS/2 KB | |
| 1*PS_ON | |
| Casing | P/G/F |
| Fan / Fanless | Fanless |
| VESA Mounting | 100*100MM |
| Dimensions (W x D x H) | 235*177*57MM |
| Packing Dimension (W x D x H) | 235*295*75MM |
| Net Weight | 2.1KG |
| Gross weight | 2.6KG |
| Consumption | 18W |
| Operating Temperature | -10°C - 50°C |
| Storage Temperature | -20°C - 70°C |
| Humidity | 10%RH - 90%RH |
| Shock / Drop | Class A Package 1~20.99 lbs（0.45~9.54㎏） 30 in /（76.20㎝） |
| Power Input | AC 100-240V/50-60HZ 1.5A |
| Power Output | DC 12V/5A |
| Safety | CE |
| IP Rating | IP54 |
