•Fast printing speed of up to 4.7 lines / sec
•Archive optimum efficiency with 3 parts forms printout (original
+ 2 copies)
•Trustworthy reliability (1.2 million lines)
•Compatible with ESC / POS command sets
•Automatic Black mark detection
•Online Parameter setting
| Print Method | Direct thermal line | |
| Print Resolution | 203dpi | |
| Max Printing Speed | 100mm/s | |
| Max Printing Width | 48mm | |
| Kitchen Print | NO | |
| OS Support | Windows OS | |
| Width | 58±0.5mm | |
| Thickness | 0.054~0.06 mm | |
| Character Set | ANK Chahacter Font A: 12×24dots Font B: 9×7dots Simplified/Traditional Chinese: 24×24dots |
|
| Character/Line | Font A - 42columns or 48columns/ Font B:56columns or 64columns/ Simplified/Traditional Chinese - 21columns or 24columns |
|
| Barcodes Supported | UPC-A/UPC-E/JAN13(EAN13)/JAN8(EAN8)CODE39/ITF/CODABAR/CODE39/CODE93/CODE128 | |
| Mechanism (km) | 150km | |
| Auto Cutter | YES | |
| Dimensions(WxDxH) | 125 W × 202 D × 102 H (mm) | |
| Packing dimension | 295 W × 210 D × 183 H (mm) | |
| Net Weight | 1.06KG | |
| Gross Weight | 2.0KG | |
| Power Input | AC 110V/220V,50-60Hz | |
| Power Output | DC 12V/3A | |
| I/O Ports | Serial/ USB/ Parallel/ Ethernet | |
| Operating Temperature | 0 to 45℃ | |
| Humidity | 10 - 80% RH | |
| Safety | FCC/ CE/ RoHS |
