• Android Operating System
• 15.6” Bezel free Slim LCD Monitor
• Flexible architectures for peripheral (MSR / VFD / ibutton /
Finger Senor)
• Space for printer
• Wide range of OS supported
• Hidden cable management
| CPU | RK3288/cortex A17 1.8G |
| Memory | 2GB / 4GB |
| Storage | 8/16/32GB SSD |
| OS Support | Android 5.1/6.1/7.1 with Google Play |
| Display Size | 15.6 Inches |
| Touch | 10-point Projected Capacitive Touch |
| Resolution | 1366 x 768 / 1920 x 1080 |
| Brightness | 220 cd/m2 |
| Backlight Type | LED |
| Contrast Ratio | 600:1 |
| Response Time | 12ms |
| Viewing Angle (Up/ Down/ Left/ Right) | IPS |
| Video Interface | EDP |
| I/O Port | DC12V IN |
| DC12V OUT | |
| 1×HDMI | |
| 6×USB2.0 | |
| 1×AUDIO | |
| 1×SD Slot | |
| 1×LAN | |
| 1×COM(DB9) | |
| 1×CASH DRAWER(RJ11) | |
| Housing Material | Magaluma |
| Tilt Angle | 0-270° |
| VESA Mounting | 75 x 75 (mm) & 100 x 100 (mm) |
| Dimensions (W x D x H) | 387 W × 200 D × 315 H (mm) |
| Packing Dimension | 440 (W) x 310 (D) x 413 (H) mm |
| Net Weight | 4.9KG |
| Gross weight | 6.8KG |
| Consumption | 35W（MAX） |
| Operating Temperature | -10˚C to 50˚C |
| Storage Temperature | -20℃ to 60℃ |
| Humidity | 10% to 85% |
| Shock / Drop | 75cm with packaging |
| Power Input | AC 100-240V |
| Power Output | DC 12V/5A |
| Safety | FCC / CE / RoHS |
| ISO Trick 1/2/3 Magnetic Stripe Reader | support |
| VFD | support |
| Second Display | 10.1" / 15" |
| iButton | Support |
| iButton+MSR | Support |
| Finger Senor | Support |
