• 220 mm / sec high-speed printing
• Japanese print head
• Japanese cutter unit
• Support NV Image download
• Automatic black mark detection
| Print Method | Direct thermal line |
| Print Resolution | 203x203 dpi |
| Max Printing Speed | 220mm/s |
| Max Printing Width | 80mm, 640 dots |
| Kitchen Print | NO |
| OS Support | up to Windows 10, Linux, OPOS |
| Width | 80mm79.5± 0.5 mm |
| Thickness | 0.065 ~ 0.15 mm |
| Character Set | ASCII: 13 international character sets |
| Character/Line | Font A - 48columns/ Font B - 64columns/ Simplified/Traditional Chinese - 21columns or 24columns |
| Barcodes Supported | Linear bar code: UPC-A, UPC-E, EAN-13, EAN-8, CODE39, CODE128, ITF-25, CODABAR Two-dimension code: PDF417, QR CODE |
| Mechanism (km) | 100km |
| Auto Cutter | YES |
| Dimensions(WxDxH) | 145 W × 200 D × 145 H (mm) |
| Packing dimension | 290 W × 235 D × 270 H (mm) |
| Net Weight | 2.03KG |
| Gross Weight | 3.36KG |
| Power Input | 40W |
| Power Output | Nil |
| I/O Ports | Serial+USB/ Parallel/ USB+Ethernet/ BT/ Wireless |
| Operating Temperature | 5 to 35℃ |
| Humidity | 25 - 80% RH |
| Safety | FCC/ CE/ RoHS |
