• True Bezel Free Designing
• High Performance 17 inch LED Panel
• 5-wire resistive touch
• Ergonomics stylish “L” shape stand
• Drip-proof sealed screen
• Optional for different stands; ISO Track 1/2/3 Magnetic Strip
Reader; VFD
| Display Size | 17 inches |
| Resolution | 1280 × 1024 |
| Brightness | 400cd /㎡ |
| Backlight Type | WLED |
| Contrast Ratio | 1000:1 |
| Response Time | 12ms |
| Viewing Angle (Up/ Down/ Left/ Right) | 80°/80°/85°/85° |
| Video Interface | LVDS |
| Touch | 5-wire Resistive / Projected Capacitive |
| I/O Port | DC 12V IN(DC 2.0) |
| 1×VGA | |
| 1×Touch USB (Type B) | |
| Housing Material | ABS+Magaluma |
| Tilt Angle | 0°~60° |
| VESA Mounting | 100×100 mm |
| Dimensions (W x D x H) | AT Stand: 395 W × 175 D × 364 H (mm) L Stand: 395 W × 195 D × 364 H (mm) |
| Packing Dimension | 490 W × 210 D × 450 H (mm) |
| Net Weight | AT Stand: 5.5KG / L Stand: 6.0KG |
| Gross weight | AT Stand: 7.2KG / L Stand: 7.7KG |
| Consumption | 25W (MAX) |
| Operating Temperature | 0 ℃ to 40℃ |
| Storage Temperature | -20℃ to 60℃ |
| Humidity | 20 - 80% RH |
| Shock / Drop | 76.2cm with packaging |
| Power Input | AC 100-240V/1.5A |
| Power Output | DC 12V/3A |
| Safety | FCC, CE, ROHS |
| IP Rating | IP 54 |
