• Reads most of the standard 1D & 2D Barcode
• Reads Barcode on Mobile Phones or Tablets
• BT Class 2 V2.1, max. 10m from host device
• Support iOS, Android or Windows OS
• Programmable button active Virtual Keyboard in iOS devices
| Radio/Range | 2.4 to 2.5 GHz (ISM Band) Adaptive Frequency Hopping BT v2.1; Class 2; 10 m (33 ft) line of sight |
| Battery | 750 mAh Li-ion minimum |
| Number of Scans | Up to 2,250 scans per full charge |
| Expected Hours of Operation | 12 hours |
| Expected Charge Time | 3 hours |
| Dimensions (LxWxH) | 120 x 48 x 22 mm (4.7 in x 1.9 in x 0.9 in) |
| Weight | < 100 g (3.5oz) |
| Temperature | Operating: 0°C to 50°C (32°F to 122°F) |
| While Charging: 0°C to 40°C (32°F to 104°F) | |
| Humidity | 0 to 95% relative humidity, non-condensing |
| Drop | Designed to withstand 30 1.4 m (4’) drops to concrete |
| Environmental Sealing | IP42 |
| Light Levels | 0 to 100,000 lux |
| Scan Pattern | Area Image (640x480 pixel array) |
| Motion Tolerance | Up to 10 cm/s (4 in/s) for 13 mil UPC at optimal focus |
| Scan Angle | Horizontal 41.4°; Vertical 32.2° |
| Symbol Contrast | 35% minimum reflectance difference |
| Decode Capability | Reads standard 1D, PDF, 2D, Postal, and OCR symbologies. Note: Decode capabilities dependent on kit configuration. |
