• Fast print speeds: Print at speeds of up to 350mm/s
• Proven reliability: Epson's proven track record for reliability
• Co-existence: Allows PC, mobile and web connection at the
same time
• Server direct print: Print directly from web server to
any connected receipt printer
| Print method | Thermal line printing |
| Column capacity | Paper width 80 mm, 58 / 80 |
| Paper size | 79.50 ± 0.50 (W) mm x dia 83.00 mm |
| 57.50 ± 0.50 (W) mm x dia 83.00 mm | |
| Print Speed | 350 mm/sec |
| Print Speed (default) | 300 mm/sec |
| Printing Font | ANK |
| Column capacity receipt | Paper width 80 mm, 58 / 80 |
| Character size | 12 mm (W) x 24 mm (H) / 99 mm (W) x 24 mm (H) |
| Character set | 95 Alphanumeric, 18 set International, 128 x 43 Graphic |
| Printing Characters | Text (incl. Euro symbol), Graphics, Barcode |
| Interfaces | USB 2.0 Type A, USB 2.0 Type B, Powered USB (optional), |
| Parallel (optional), RS-232(optional), Ethernet interface | |
| (100 Base-TX / 10 Base-T), Wireless LAN IEEE 802.11b/g/n | |
| (optional), Wireless LAN IEEE 802.11a/b/g/n (optional), | |
| Drawer kick-out, Bluetooth (optional) | |
| Data Buffer | 4 kB or 45 Bytes |
| Power Supply | PS-180, AC cable |
| Operatingvoltage | 24 V |
| Product dimensions | 145 x 195 x 148 mm (Width x Depth x Height) |
| Product weight | 1.6 kg |
| Colour | Black / White |
| Installation | horizontally, wall hanging |
| Interface connectors | D.K.D. function |
| Humidity | Operation 10% - 90% |
| Temperature | Operation 5° C - 45° C, Storage -10° C - 50° C |
| EMC Standards | CE marking, EN55024 |
| Safety standards | UL, CSA |
