(Phased-Out)
| CPU | Intel® Core™ i5-3210M Processor |
| Memory | DDRIII 4GB |
| Storage | 128G(SSD) |
| OS Support | Windows 7, Windows 8.1, Windows Embedded 8.1 Industry, Windows 10, Windows 10 IOT, POS Ready 7, Linux (ubuntu) |
| Display Size | 15" |
| Resolution | 1024 x 768 |
| Brightness | 250 cd /㎡ |
| Backlight Type | LED |
| Contrast Ratio | 700 : 1 |
| Response Time | 16ms |
| Viewing Angle (Up/ Down/ Left/ Right) | 70°/ 70°/ 80°/ 80° |
| Video Interface | LVDS |
| Touch | 5-wire Resistive |
| I/O Port | DC 12V IN |
| 1×VGA | |
| 4×USB2.0 | |
| 2×USB3.0 | |
| 1×LAN | |
| 1×PS/2 | |
| 1×AUDIO | |
| 4×COM(DB9) | |
| 1×CASH DRAWER(RJ11) | |
| Housing Material | Aluminum |
| Tilt Angle | 0˚~70° |
| VESA Mounting | 75 x 75 (mm) & 100 x 100 (mm) |
| Dimensions (W x D x H) | 358 x 229 x 302 (mm) |
| Packing Dimension | 480 x 360 x 435 (mm) |
| Net Weight | 7.5Kg |
| Gross weight | 8.5Kg |
| Consumption | 55W（MAX） |
| Operating Temperature | 0 ℃ to 40℃ |
| Storage Temperature | -20℃ to 60℃ |
| Humidity | 10% to 80% |
| Shock / Drop | 100cm with packaging |
| Power Input | AC 100-240V /2.5A 50-60Hz |
| Power Output | DC 12V/6.66A |
| Safety | FCC/ CE |
| IP Rating | - |
| ISO Trick 1/2/3 Magnetic Stripe Reader | ISO Trick 1/2/3 Magnetic Stripe Reader(USB) |
| VFD | 20 columns x 2 lines(USB or RS232) |
| Second Display (9.7", 10.1", 12", 15") | 8"&10.4"(USB) / 15"(VGA) |
| Wireless | 802.11n , 2.4G(Mini PCIe) |
| iButton | 1-Wire(USB) |
| iButton+MSR | N/A |
| Finger Senor | N/A |
